High-Linearity, 1700MHz to 2200MHz Upconversion/
Downconversion Mixer with LO Buffer/Switch
ABSOLUTE MAXIMUM RATINGS
V CC to GND ...........................................................-0.3V to +5.5V
TAP, LOBIAS, LOSEL to GND ....................-0.3V to (V CC + 0.3V)
LO1, LO2, IF+, IF- to GND ....................................-0.3V to +0.3V
RF, IF, LO1, LO2 Input Power ........................................+15dBm
RF (RF is DC shorted to GND through a balun) .................50mA
Continuous Power Dissipation
θ JA .................................................................................+33°C/W
θ JC ...................................................................................+8°C/W
Operating Temperature Range (Note A) ....T C = -40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +165°C
Lead Temperature (soldering, 10s) .................................+300°C
20-Pin QFN-EP (derate 20mW/°C above T A = +70°C) ....2.2W
Note A: T C is the temperature on the exposed paddle of the package.
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
DC ELECTRICAL CHARACTERISTICS
(MAX2039 Typical Application Circuit , V CC = +4.75V to +5.25V, T C = -40°C to +85°C, no RF signals applied, IF+ and IF- DC ground-
ed through a transformer. Typical values are at V CC = +5V, T C = +25°C, unless otherwise noted.)
PARAMETER
Supply Voltage
Supply Current
SYMBOL
V CC
I CC
CONDITIONS
MIN
4.75
TYP
5.00
104
MAX
5.25
135
UNITS
V
mA
LO_SEL Input Logic Low
LO_SEL Input Logic High
V IL
V IH
2
0.8
V
V
AC ELECTRICAL CHARACTERISTICS (DOWNCONVERTER OPERATION)
(MAX2039 Typical Application Circuit , V CC = +4.75V to +5.25V, T C = -40°C to +85°C, RF and LO ports are driven from 50 Ω sources,
P LO = -3dBm to +3dBm, P RF = 0dBm, f RF = 1700MHz to 2200MHz, f LO = 1500MHz to 2000MHz, f IF = 200MHz, f RF > f LO , unless oth-
erwise noted. Typical values are at V CC = +5V, P RF = 0dBm, P LO = 0dBm, f RF = 1900MHz, f LO = 1700MHz, f IF = 200MHz, T C =
+25°C, unless otherwise noted.) (Notes 1, 2)
PARAMETER
RF Frequency Range
LO Frequency Range
IF Frequency Range
Conversion Loss
SYMBOL
f RF
f LO
f IF
L C
CONDITIONS
(Note 3)
(Note 3)
(Contact factory)
External IF transformer dependent
P RF < +2dBm
MIN
1700
1500
1900
DC
TYP
7.1
MAX
2200
2000
2400
350
UNITS
MHz
MHz
MHz
dB
Loss Variation Over Temperature
T C = -40°C to +85°C
0.0075
dB/°C
Input Compression Point
P 1dB
(Note 4)
24.4
dBm
Two tones:
f RF1 = 2000MHz,
Input Third-Order Intercept Point
IIP3
f RF2 = 2001MHz,
P RF = +5dBm/tone,
31
34.5
dBm
f LO = 1800MHz,
P LO = 0dBm
Input IP3 Variation Over
Temperature
T C = -40°C to +85°C
±0.75
dB
Noise Figure
NF
Single sideband
7.3
dB
